| Supply Voltage | 90 – 270 V AC/DC 24 V DC on Request |
|
| Temperature And Humidity | Operating : 0 – 50’C 95% RH |
|
| Dimensions in mm (H x W x D) | 48 x 48, 48 x 96, 72 x 72, 96 x 96 mm | |
| Display | Height | 0.36” or 0.56” |
| No of Digit | 4 Digit Single or Dual Raw | |
| LED Indication | Output Status, Soak Time, AT | |
| Measurement | Sensor Input | PT-100, J, K, R, S |
| Resolution | PT-100 : 0.1’C/ 1’C, T/C : 1’C | |
| Sampling Rate | 250 msec | |
| Accuracy | 0.3% FS | |
| Output1 | Relay | 5A @ 250 VAC/ 30 V DC |
| SSR Drive | 12 VDC @ 30mA | |
| Output2 | Alarm | Low/ High/ Band Low Deviation/ High Deviation |
| Soak Timer | Heater off/ Alarm/ Both | |
| Retransmission/ Control | 4-20 mA or 0-10 V DC |
Flame proof Indicators / Controller
| Enclosure | Flameproof Certified for Gas Group IIA & IIB |
| Supply Voltage | 230 V AC |
| Control Action | On/Off / Time Proportional / PID |
| Display | 4 Digit 0.36” or 0.56” |
| Sensor Input | PT-100, J, K, R, S |
| Resolution | PT-100 : 0.1’C/ 1’C, T/C : 1’C |
| Sampling Rate | 250 msec |
| Accuracy | ±0.25% of FS ± 1 COUNT |
| Output | 1 or 2 Relay/SSR Contact |
| Cable Entry | ¾” ET or ½” NPT |
Jumbo Display
| Supply Voltage | 230 V AC | |
| Temperature And Humidity | Operating : 0 – 50’C 95% RH |
|
| Dimensions in mm (H x W x D) | 120 x 230 x 80 mm 165 x 390 x 50 mm |
|
| Display | Height | 2.7” or 4” Red |
| No of Digit | 4 Digit Single Raw | |
| Measurement | Sensor Input | PT-100, J, K, R, S Analog : 0-1 VDC, 0-3.3 VDC, 0-5 VDC, 0-10 VDC, 0-20 mA, 4-20 mA |
| Resolution | PT-100 : 0.1’C/ 1’C, T/C : 1’C Analog : 1/ 0.1/ 0.01/ 0.001 |
|
| Sampling Rate | 250 msec | |
| Accuracy | 0.3% FS |
